How Carnivore Worked

By: Jeff Tyson
An FBI agent using a laptop.
Carnivore was a program developed by the FBI. Nes / Getty Images

You may have heard about Carnivore, a controversial program developed by the U.S. Federal Bureau of Investigation (FBI) to give the agency access to the online/e-mail activities of suspected criminals. For many, it is eerily reminiscent of George Orwell's book "1984." Although Carnivore was abandoned by the FBI in favor of commercially available eavesdropping software by January 2005, the program that once promised to renew the FBI's specific influence in the world of computer-communications monitoring is nonetheless intriguing in its structure and application.

Advertisement

Carnivorous Evolution

Carnivore was the third generation of online-detection software used by the FBI. While information about the first version has never been disclosed, many believe that it was actually a readily available commercial program called Etherpeek.

In 1997, the FBI deployed the second generation program, Omnivore. According to information released by the FBI, Omnivore was designed to look through e-mail traffic travelling over a specific Internet service provider (ISP) and capture the e-mail from a targeted source, saving it to a tape-backup drive or printing it in real-time. Omnivore was retired in late 1999 in favor of a more comprehensive system, the DragonWare Suite, which allowed the FBI to reconstruct e-mail messages, downloaded files or even Web pages.

Advertisement

DragonWare contained three parts:

  • Carnivore - A Windows NT/2000-based system that captures the information
  • Packeteer - No official information released, but presumably an application for reassembling packets into cohesive messages or Web pages
  • Coolminer - No official information released, but presumably an application for extrapolating and analyzing data found in the messages

­ As you can see, officials never released much information about the DragonWare Suite, nothing about Packeteer and Coolminer and very little detailed information about Carnivore. But we do know that Carnivore was basically a packet sniffer, a technology that is quite common and has been around for a while.

Advertisement

Packet Sniffing

Computer network administrators have used packet sniffers for years to monitor their networks and perform diagnostic tests or troubleshoot problems. Essentially, a packet sniffer is a program that can see all of the information passing over the network it is connected to. As data streams back and forth on the network, the program looks at, or "sniffs," each packet.

Normally, a computer only looks at packets addressed to it and ignores the rest of the traffic on the network. When a packet sniffer is set up on a computer, the sniffer's network interface is set to promiscuous mode. This means that it is looking at everything that comes through. The amount of traffic largely depends on the location of the computer in the network. A client system out on an isolated branch of the network sees only a small segment of the network traffic, while the main domain server sees almost all of it.

Advertisement

A packet sniffer can usually be set up in one of two ways:

  • Unfiltered - Captures all of the packets
  • Filtered - Captures only those packets containing specific data elements

­ Packets that contain targeted data are copied as they pass through. The program stores the copies in memory or on a hard drive, depending on the program's configuration. These copies can then be analyzed carefully for specific information or patterns.

When you connect to the Internet, you are joining a network maintained by your ISP. The ISP's network communicates with other networks maintained by other ISPs to form the foundation of the Internet. A packet sniffer located at one of the servers of your ISP would potentially be able to monitor all of your online activities, such as:

  • Which Web sites you visit
  • What you look at on the site
  • Whom you send e-mail to
  • What's in the e-mail you send
  • What you download from a site
  • What streaming events you use, such as audio, video and Internet telephony
  • Who visits your site (if you have a Web site)

In fact, many ISPs use packet sniffers as diagnostic tools. Also, a lot of ISPs maintain copies of data, such as e-mail, as part of their back-up systems. Carnivore and its sister programs were a controversial step forward for the FBI, but they were not new technology.

Advertisement

The Carnivore Process

Now that you know a bit about what Carnivore was, let's take a look at how it worked:

The FBI has a reasonable suspicion that someone is engaged in criminal activities and requests a court order to view the suspect's online activity. A court grants the request for a full content-wiretap of e-mail traffic only and issues an order.

Advertisement

A term used in telephone surveillance, "content-wiretap" means that everything in the packet can be captured and used. The other type of wiretap is a trap-and-trace, which means that the FBI can only capture the destination information, such as the e-mail account of a message being sent out or the Web-site address that the suspect is visiting. A reverse form of trap-and-trace, called pen-register, tracks where e-mail to the suspect is coming from or where visits to a suspect's Web site originate.

The FBI contacts the suspect's ISP and requests a copy of the back-up files of the suspect's activity. The FBI sets up a Carnivore computer at the ISP to monitor the suspect's activity. The computer consists of:

  • A Pentium III Windows NT/2000 system with 128 megabytes (MB) of RAM
  • A commercial communications software application
  • A custom C++ application that works in conjunction with the commercial program above to provide the packet sniffing and filtering
  • A type of physical lockout system that requires a special passcode to access the computer (This keeps anyone but the FBI from physically accessing the Carnivore system.)
  • A network isolation device that makes the Carnivore system invisible to anything else on the network (This prevents anyone from hacking into the system from another computer.)
  • A 2-gigabyte (GB) Iomega Jaz drive for storing the captured data (The Jaz drive uses 2-GB removable cartridges that can be swapped out as easily as a floppy disk.)

The FBI configures the Carnivore software with the IP address of the suspect so that Carnivore will only capture packets from this particular location. It ignores all other packets. Carnivore copies all of the packets from the suspect's system without impeding the flow of the network traffic. Once the copies are made, they go through a filter that only keeps the e-mail packets. The program determines what the packets contain based on the protocol of the packet. For example, all e-mail packets use the Simple Mail Transfer Protocol (SMTP). The e-mail packets are saved to the Jaz cartridge. Once every day or two, an FBI agent visits the ISP and swaps out the Jaz cartridge. The agent takes the retrieved cartridge and puts it in a container that is dated and sealed. If the seal is broken, the person breaking it must sign, date and reseal it -- otherwise, the cartridge can be considered "compromised." The surveillance cannot continue for more than a month without an extension from the court. Once complete, the FBI removes the system from the ISP. The captured data is processed using Packeteer and Coolminer. If the results provide enough evidence, the FBI can use them as part of a case against the suspect.

The ISP does not maintain customer-activity data as part of its back-up.

The example above shows how the system identified which packets to store.

Advertisement

Prey of the Carnivore

The FBI planned to use Carnivore for specific reasons. Particularly, the agency would request a court order to use Carnivore when a person was suspected of:

  • Terrorism
  • Child pornography/exploitation
  • Espionage
  • Information warfare
  • Fraud

There are some key issues that caused a great deal of concern from various sources:

Advertisement

  • Privacy - Many folks viewed Carnivore as a severe violation of privacy. While the potential for abuse is certainly there, the Electronic Communications Privacy Act (ECPA) provides legal protection of privacy for all types of electronic communication. Any type of electronics surveillance requires a court order and must show probable cause that the suspect is engaged in criminal activities. Therefore, use of Carnivore in any way that did not adhere to ECPA was illegal and could be considered unconstitutional.
  • Regulation - There was a widespread belief that Carnivore was a huge system that could allow the U.S. government to seize control of the Internet and regulate its use. To do this would have required an amazing infrastructure -- the FBI would have needed to place Carnivore systems at every ISP, including private, commercial and educational. While it is theoretically possible to do so for all of the ISPs operating in the United States, there is still no way to regulate those operating outside of U.S. jurisdiction. Any such move would have also faced serious opposition from every direction.
  • Free speech - Some people think that Carnivore monitored all of the content flowing through an ISP, looking for certain keywords such as "bomb" or "assassination." Any packet sniffer can be set to look for certain patterns of characters or data. Without probable cause, though, the FBI had no justification to monitor your online activity and would have been in severe violation of ECPA and your constitutional right to free speech if it did so.
  • Echelon - This is a secret network rumored to be under development by the National Security Agency (NSA), supposedly designed to detect and capture packets crossing international borders that contain certain keywords, such as "bomb" or "assassination." There is no solid evidence to support the existence of Echelon. Many people confused this rumored system with the Carnivore system.

­ All of these concerns made the implementation of Carnivore an uphill battle for the FBI. The FBI refused to disclose the source code and certain other pieces of technical information about Carnivore, which only added to people's concerns. But, as long as it was used within the constraints and guidelines of ECPA, Carnivore had the potential to be a useful weapon in the war on crime.

Advertisement

Frequently Answered Questions

Which government agency has the Carnivore program?
The Carnivore program is a controversial software surveillance system run by the FBI.
